f4i key bypass
Hi stunters I lost my key to my F4i and wondering is there any way i can bypass this?
itzmatty is offline
Reply
Old 11-20-2006, 10:14 AM
  #2
Scrapes Elbow

Wheeliest's Avatar

Join Date: May 2004
Location: Phoenix, AZ.
Age: 41
Posts: 8,833
Wheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to all
Re: f4i key bypass
u can bypass it by getting a new key. dealership should beable to make u a copy if u take them your title.
Wheeliest is offline
Reply
Old 11-20-2006, 10:33 AM
  #3
bp chaser

MikeM's Avatar

Join Date: Oct 2002
Location: LI, NY and I drive in Australia
Age: 47
Posts: 85,366
MikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for rep
Re: f4i key bypass
Power comes from Red, so if you're gonna have a switch, put it there.
Blue/Yellow and Red/Black get soldered together
That should leave only the pink wire that goes to the ecu. You need to put a diode on there, I think 7 volts is what the ecu wants (if i rmember correctly)

check out my kick *** wiring diagram
Attached Thumbnails Click image for larger version Name: ignitionswitch2.jpg Views: 630 Size: 45.3 KB ID: 183789
MikeM is offline
Reply
Old 11-20-2006, 11:48 AM
  #4
I Enjoy Posting At StuntLife!

Skunky's Avatar

Join Date: Aug 2003
Location: Manchester, NH
Age: 44
Posts: 2,866
Skunky is an unknown quantity at this point
Re: f4i key bypass
take a security bit and unscrew he three holding in the mechanism....from underneath,,,,,take a screw driver and trun the white plastic piece in the middle clockwise and the bike will get power.
Skunky is offline
Reply
Old 11-20-2006, 11:50 AM
  #5
Retired

NINER's Avatar

Join Date: Mar 2003
Location: .
Posts: 37,967
NINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for rep
Re: f4i key bypass
Originally Posted by Skunky
take a security bit and unscrew he three holding in the mechanism....from underneath,,,,,take a screw driver and trun the white plastic piece in the middle clockwise and the bike will get power.
That's a pain in the ***. It is a lot easier to cut the wires and break open the plastic cover on the bottom to take the resister/diode thing you need out.
NINER is offline
Reply
Old 11-20-2006, 11:53 AM
  #6
Scrapes Elbow

Wheeliest's Avatar

Join Date: May 2004
Location: Phoenix, AZ.
Age: 41
Posts: 8,833
Wheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to all
Re: f4i key bypass
does that resistor open gas caps too
Wheeliest is offline
Reply
Old 11-20-2006, 11:58 AM
  #7
Retired

NINER's Avatar

Join Date: Mar 2003
Location: .
Posts: 37,967
NINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for rep
Re: f4i key bypass
Originally Posted by Wheeliest
does that resistor open gas caps too
Vortex cap. If you ever dented a honda tank with a stock cap you know why.
NINER is offline
Reply
Old 11-20-2006, 12:03 PM
  #8
Scrapes Elbow

Wheeliest's Avatar

Join Date: May 2004
Location: Phoenix, AZ.
Age: 41
Posts: 8,833
Wheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to all
Re: f4i key bypass
i suppose. my tank had a reg honda cap and a huge dent no leak issues.
Wheeliest is offline
Reply
Old 11-20-2006, 12:05 PM
  #9
Retired

NINER's Avatar

Join Date: Mar 2003
Location: .
Posts: 37,967
NINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for repNINER User spends way too much time asking for rep
Re: f4i key bypass
Originally Posted by Wheeliest
i suppose. my tank had a reg honda cap and a huge dent no leak issues.
You got lucky then. Most crack. Yopu can also open the gas cap with a screwdriver and a wrench, but then you have to carry that **** around with you every time.
NINER is offline
Reply
Old 11-20-2006, 12:13 PM
  #10
Scrapes Elbow

Wheeliest's Avatar

Join Date: May 2004
Location: Phoenix, AZ.
Age: 41
Posts: 8,833
Wheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to all
Re: f4i key bypass
i also got lucky later that night
Wheeliest is offline
Reply
Old 11-20-2006, 01:39 PM
  #11
I Enjoy Posting At StuntLife!

Skunky's Avatar

Join Date: Aug 2003
Location: Manchester, NH
Age: 44
Posts: 2,866
Skunky is an unknown quantity at this point
Re: f4i key bypass
hahahaha
Skunky is offline
Reply
Old 11-21-2006, 05:19 PM
  #12
Registered User

Scott-'s Avatar

Join Date: Apr 2006
Location: Apple Valley CA
Age: 43
Posts: 4,923
Scott- is an unknown quantity at this point
Re: f4i key bypass
Originally Posted by MikeM
Power comes from Red, so if you're gonna have a switch, put it there.
Blue/Yellow and Red/Black get soldered together
That should leave only the pink wire that goes to the ecu. You need to put a diode on there, I think 7 volts is what the ecu wants (if i rmember correctly)

check out my kick *** wiring diagram
I GOT MY BIKE FROM A POLICE AUCTION IT CAME WITH NO KEYS SO TO SEE HOW MANY MILES IT HAD ON IT I PUT ALL THE WIRES TOGETHER WOULD THIS F U C K UP THE ECU
Scott- is offline
Reply
Old 11-21-2006, 05:39 PM
  #13
Registered User

skidmark's Avatar

Join Date: Nov 2002
Location: Vancouver
Age: 44
Posts: 1,553
skidmark is a decent person
Re: f4i key bypass
There are numbers on the bottom of your ignition... write em down and go to a REAL key-maker / locksmith (not the key-cutter at walmart) and they should be able to make you a key on the spot if they have the blank, which they should. You can also take the ignition (still in the triple if you can't get it out) to the locksmith if you can't find/read the #'s

I broke my key somehow a few weeks ago (had it in my toolbox) and just had 2 fresh ones made from the numbers in less than 15 minutes
skidmark is offline
Reply
Old 11-21-2006, 06:24 PM
  #14
Registered User

Scott-'s Avatar

Join Date: Apr 2006
Location: Apple Valley CA
Age: 43
Posts: 4,923
Scott- is an unknown quantity at this point
Re: f4i key bypass
Is The Key Code Mixed #s And Letters 6 Of Them
Scott- is offline
Reply
Old 11-21-2006, 11:27 PM
  #15
Scrapes Elbow

Wheeliest's Avatar

Join Date: May 2004
Location: Phoenix, AZ.
Age: 41
Posts: 8,833
Wheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to allWheeliest is a name known to all
Re: f4i key bypass
its by the stem lock.
Wheeliest is offline
Reply
Old 11-22-2006, 12:06 AM
  #16
Registered User

Scott-'s Avatar

Join Date: Apr 2006
Location: Apple Valley CA
Age: 43
Posts: 4,923
Scott- is an unknown quantity at this point
Re: f4i key bypass
cool i got it thanx wheeliest sweet avitar by the way
Scott- is offline
Reply
Old 11-22-2006, 01:11 AM
  #17
lky
Registered User

lky's Avatar

Join Date: Dec 2003
Location: Sydney Australia
Age: 41
Posts: 1,241
lky is an unknown quantity at this point
Re: f4i key bypass
MikeM you are a genius

p.s thats a wicked wiring diagram
lky is offline
Reply
Old 11-22-2006, 03:56 AM
  #18
www.ChicagoRiders.com

Robbie's Avatar

Join Date: May 2003
Location: Chicago, IL
Posts: 7,911
Robbie can only hope to improve
Re: f4i key bypass
I lost my key also and want to use one one of the methods here for my f4i.
Problem is I locked my stearing up, how can I "break" it lose?

Thanks.
Robbie is offline
Reply
Old 11-22-2006, 04:04 AM
  #19
Registered User

letsride's Avatar

Join Date: Apr 2006
Location: Northeast
Age: 40
Posts: 12,123
letsride is a name known to allletsride is a name known to allletsride is a name known to allletsride is a name known to allletsride is a name known to allletsride is a name known to all
Re: f4i key bypass
Originally Posted by Robbie
I lost my key also and want to use one one of the methods here for my f4i.
Problem is I locked my stearing up, how can I "break" it lose?

Thanks.

letsride is offline
Reply
Old 11-22-2006, 08:35 AM
  #20
bp chaser

MikeM's Avatar

Join Date: Oct 2002
Location: LI, NY and I drive in Australia
Age: 47
Posts: 85,366
MikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for repMikeM User spends way too much time asking for rep
Re: f4i key bypass
Originally Posted by lky
MikeM you are a genius

p.s thats a wicked wiring diagram
i heard it from niner, i cant take the credit
